Bianchi Arcadex Grx810 2026

Specificaties

Frameset
Frame Arcadex Comp Disc Brake Specification: Flat Mount 140/160 Bottom Braket Standard: PressFit 86.5 X Ø41 Rear Axle: thru12 OLD (Over-Locknut-Dimension): 142 mm Front Derailleur:Non Compatible Rear Derailleur: SRAM UDH Hanger type Max Chainring Compatibility:
Fork Bianchi Arcadex Fork Disc Brake Specification: Flat Mount 140/160 Front Axle: thru12 OLD (Over-Locknut-Dimension): 100 mm Tire Clearance: ETRTO 622-42mm Steer tube Diameter: 1 1/8"" Material: Epoxy - SM Carbon Fiber Composite
Headset Bianchi Custom Acros ICR (Internal Cable Rounting) Spacers:5 mm x1, 10mm x3 Headtube Cover: Bianchi Costum Compresion Ring: 1.125 Inch Top Bearing: Angular contact Bearing 42x52x7 + seal Bottom Bearing: Angular contact Bearing 40x52x7 + seal

Drivetrain
Shifters Shimano GRX 610 ST/BL-RX610
Rear Derailleur Shimano GRX 822 RD-RX822, SGS Maximum Cassette Sprocket 51T
Crankset Shimano GRX 610 FC-RX610-1, 40T Crank Length: 170mm-XS(47)-SM(51), 172.5mm-MD(55)-LG(58), 175mm-XL(61)
Bottom Bracket Shimano SM-BB72-41B, press fit
Chain Shimano CN-M7100
Cassette Shimano CS-M7100-12 speed, 11-51T Driver body Interface: MicroSpline

Brakes
Brakes
Shimano Hydraulic Brake, BR-RX400
Rotor
Shimano SM-RT70 IceTech Hub Interface: Centerlock Rotor Diameter: 160 mm (front&Rear)

Wheels
Wheels
Fulcrum RapidRed 900 2-Way Fit Ready (for clincher and tubeless ready) Rim Diameter: 700C Material: Aluminum Alloy Rim Height: 24 mm Inner Wigth Channel: 22 mm
Tire
Pirelli Cinturato™ GRAVEL M Classic, 45-622 tan sidewall

Cockpit
Stem
Velomann AICR Alloy Rise: -2° Steerer Diameter: 1-1/8"" (28.6mm) HB interface Diameter: 1-1/4"" (31.8mm) Stem Lengths: 80mm - XS(47), 90mm - SM(51), 100mm-MD(55), 110mm-LG(58),120m -XL(61)
Handlebar
Velomann Gravel ICR Alloy Flare: 16° Drop: 130mm Reach 70mm Interface Diameter: 1 1/4"" (31.8mm) HandleBar Widths: 400 - SX(47) SM(51), 420 - MD(55) LG(58), 440 -XL(61)
Grips / Extensions
Bianchi Hexagon tape 2.5mm thickness, Full black

Saddle
Seatpost
Velomann Carbon UD SeatPost O.D: Ø27.2 mm Seatpost lengths: 300mm-SX(47), 350mm- SM(51) MD(55), LG(58) XL(61)
Saddle
Velomann MITORA 149 H2 cover: soft touch, padding: foam, shell: nylon carbon rails: Steel lenght: 250mm width: 149mm

Beschrijving

Ontdek nieuwe wegen met de Bianchi Arcadex Comp, een gravelbike die prestaties en avontuur perfect combineert. Het lichtgewicht carbon frame met geïntegreerde kabels zorgt voor een strakke look en optimale aerodynamica, terwijl de comfortabele geometrie stabiliteit biedt op zowel verharde als onverharde paden.
